IC Logic Gate 74LS32N OR

The IC 74LS32 is designed with four OR Gates, each having two inputs (A and B) and one output (Q). It operates within a voltage supply range of 5 to 7V and can handle input voltages in the same range. With an operating temperature range of -55°C to 125°C, it is suitable for various environments. This IC is available in a 14-pin Small Outline Integrated Circuit (SOIC) package.

Features:

• Four OR Gates in a DIP package

• Dual Input OR Gate

• Quad Package

• Supply Voltage: 5 to 7V

• Input Voltage: 5 to 7V

• Operating Temperature Range: -55°C to 125°C

• Available in 14-pin SOIC package

Applications:

• Basic logic circuits

• Encoders and decoders

• Multiplexers and demultiplexers

• Oscillator circuits

• Networking and digital systems

Package Includes:

• 1 x 74LS32 Quad 2-Input OR Gate IC
