  3. Keyestudio ESP8266 CP2101 Wi-Fi Module + 1m Micro USB Cable
Default
Keyestudio ESP8266 CP2101 Wi-Fi Module + 1m Micro USB Cable

Keyestudio ESP8266 CP2101 Wi-Fi Module + 1m Micro USB Cable

The Keyestudio Dot Matrix 8x16 LED Board features a 128-LED grid controlled via I2C communication, making it perfect for microcontroller projects. It offers adjustable brightness, easy wiring with a 4Pin HX-2.54 connector, and is ideal for creating custom patterns, text displays, and animations.

82.95 AED 82.95 AED Tax Included
82.95 AED Tax Included

Not Available For Sale

This combination does not exist.

Contact Us

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Share

The Keyestudio Dot Matrix 8x16 LED Board is a versatile display module featuring 128 bright LEDs arranged in an 8x16 grid. Powered by the AIP1640 chip on the back, this matrix offers efficient control via I2C communication, making it ideal for microcontroller-based projects. With its adjustable brightness and compact design, this LED board is perfect for creating custom patterns, text displays, and animations. To simplify wiring, it includes a 4Pin HX-2.54 connector and cable. Its 2.2mm fixed mounting holes make it easy to install on various devices, ensuring convenience and flexibility for DIY electronics enthusiasts.

Features:

  • Bright 8x16 LED Grid: Displays clear patterns, text, and animations.
  • AIP1640 Chip Control: Enables easy management of LEDs via I2C communication.
  • 4Pin Interface: Includes GND, VCC, SDA, SCL for simple connection.
  • Adjustable Brightness: Control the LED brightness through programming.
  • Sturdy Build: Features 2.2mm fixed mounting holes for secure installation.
  • Easy Wiring: Comes with an HX-2.54 4Pin cable for seamless integration.

Specifications:

SpecificationDetails
LED Arrangement8x16 grid (128 LEDs)
Control ChipAIP1640
Communication InterfaceI2C (GND, VCC, SDA, SCL)
Brightness AdjustmentProgrammable in code
Connector TypeHX-2.54 4Pin
Mounting Holes4 holes, 2.2mm diameter
LED Pitch4mm
DimensionsCompact and easy to integrate

Pinout:

Dot Matrix 8x16 LED Board Pinout
PinFunctionDescription
GNDGroundConnect to the ground of the power supply.
VCCPower SupplyConnect to 5V for power.
SDAData LineI2C data line for communication.
SCLClock LineI2C clock line for synchronization.

Applications:

  • Custom text and graphic displays.
  • Scrolling message boards.
  • IoT interfaces and data visualization.
  • Educational and prototyping projects.
  • Interactive devices and animations.

Package Includes:

  • 1 x 8x16 LED Matrix Board (4mm pitch).
  • 1 x HX-2.54 4Pin Cable.
